The digital outputs are suitable for limit value monitoring or energy metering.

• With 4 analog and 2 digital outputs
• 2 programmable energy meters for Ah, kVAh, kWh and kvarh
• Programmable application (type of electrical system)
• Current to 10 A, voltage to 830 V
• Programmable universal analog outputs
• Accuracy: U/I 0.2%, P 0.25% under reference conditions
• Universal digital outputs: meter transmitter, limit values
• Password protected software for programming, data analysis and simulation
• AC-DC power pack with large tolerance range, or AC only
• CSA certificate
• Housings: SINEAX: top-hat rail or wall mounting

1 Istruzioni operative SINEAX DME 442 in 3 lingue: tedesco, francese, inglese

1 etichetta bianca per la registrazione di dati
