IZYTRONIQ Business

SKU: S101ZZCategoria: Etichette: , , ,

Database software with report editor and barcode generator for managing equipment, machines, systems and medical devices

Business Starter/Advanced

  • Tree structure for stationary objects 1
  • Tree structure for portable devices 2
  • Tree structure for locations (properties, buildings, floors and rooms)
  • Test instrument and catalog management
  • Create device sequences
  • Catalog editor
  • User administration
  • Active/inactive (remove instruments from service)
Business Professional (in addition to Business Advanced)
  • Document management – add attachments to instruments, delete reports
  • MULTI changes
  • Save / delete filter
  • Save / delete selection of tree structure (quick links)
  • Create remote sequences (IZY-Remote)
  • Analysis and trending for identical test sequences of a given object
  • PDF printout with global statistics including failure rate as percentage
Business Premium (in addition to Business Professional)
  • Extended registration card with individual data fields
  • Role and rights management for users
  • Import with attachments (IZY file)
  • Export with attachments (IZY file)
1 (Machine & System)
2 (Devices & medical devices)

Minimum Requirements:

Minimum software components:
Operating system: Windows 10 Version 1809
.NET Framework 4.6.1*

Minimum  hardware components:
CPU: Duocore i3 > 3.4 GHz (only x86 and x64-Processors are supported)
RAM: ≥ 4 GB
Hard disk: at least 4 GB available memory (depending on data volume)
Resolution: 1280 x 800

Recommended software components:
Operating system: Windows 10 Version 1909
.NET Framework 4.6.1* Hardware

Recommended hardware components:
CPU: Quad Core i7 2.8 GHz (only x86 and x64-Processors are supported)
RAM: ≥ 8 GB
Hard disk: at least 4 GB available memory (depending on data volume)
Resolution: 1920 x 1080 – Touchscreen and active pen

  • IZYTRONIQ is newly developed test software with which the entire testing scenario can be visualized, managed and documented in an audit-proof, instrument-independent fashion.
  • IZYTRONIQ offers a modern report layout based on Microsoft Word which permits quick and easy automated generation of highly professional reports, tables, graphics and documents using any desired current data.
  • Thanks to its modular design, IZYTRONIQ can be adapted to the customer’s actual needs. If requirements for your test management system become more extensive, IZYTRONIQ can be subsequently expanded as desired.
  • The user interface was developed in keeping with the principle of quick and easy acquisition of complex structures.
  • IZYTRONIQ automatically detects and manages interconnected test instruments and queries their available scope of functions.
  • The synchronization of memory structures and measured values has been greatly simplified by means of intelligent test data import and export.

IZYTRONIQ permits acquisition of measurement data and management of test objects and testing, as well as simple, audit-proof documentation for the testing of devices, systems, machines and medical devices.

Version overview IZYTRONIQ

IZYTRONIQ was developed for use in industrial and trade operations with their own electrical departments, for vocational and further training, and for service and repair applications in the electrical trades.
