LABKON P800 80/10
Laboratory power supplies, computer controllable
LABKON P series computer controllable KONSTANTERs provide their users with manual and remote controllable DC power supplies for laboratory and system use.
The series of instruments covers nominal power ratings of 500 to 800 W with output voltages ranging from 35 to 120 V and current up to 22.5 A.
- Power: 800 W
- Voltage up to 120 V, current up to 10 A
- CV and CC operating modes, automatic switching
- Output voltage and output current can be continuously regulated from 0 up to nominal value.
- Several groups of parameters (device settings) can be saved and retrieved.
- Floating power output / no grounding
- Highly efficient
- Safe electrical separation
- Output can be switched on and off
- Supports SCPI (standard commands for programmable instruments)
- Settings selected by means of rotary switch and keypad
- Multifunctional LCD panel
- Protective functions, amongst others overvoltage protection
- Auto-sensing mode
- Benchtop instrument, also suitable for mounting to a 19″ rack
- Rugged and compact with simple handling
- RS 232 port, optional GPIB (IEEE-488) and USB interfaces
- Calibration (adjustment) function
- Power: 500 or 800 W,
- voltage: up to 120 V, current: up to 22.5 A
- CV and CC operating modes, automatic switching
- Output voltage and output current can be continuously regulated from 0 up to nominal value
- Several groups of parameters (device settings) can be saved and retrieved.
- Floating power output / no grounding
- Highly efficient
- Safe electrical separation
- Output can be switched on and off
- Supports SCPI (standard commands for programmable instruments)
- Settings selected by means of rotary encoder and keypad
- Multifunctional LCD panel
- Protective devices – amongst others overvoltage protection
- Auto-sensing mode
- Benchtop instrument, also suitable for mounting to a 19″ rack
- Rugged and compact with simple handling
- RS 232 port, optional GPIB and USB
- Calibration (adjustment) function
- Type LABKON P800
- Power (W) 800
- Voltage (V) 0-80
- Current (A) 0-10
- Article No. K159A
1 Benchtop instrument
1 Rubber protector
1 Mains cable (earthing contact)
1 Safety precautions
1 CD ROM with operating instructions (German and English)
